Inside Diameter (ID) in mm (inches)

25 (1")

Flange

ISO-KF (compatible with ISO 2861 T1)

Body Material

Aluminum

Actuator

electromagnetic with position indicator single acting closing spring

Solenoid

No

Position Indicator

Yes

Pressure Min

1•10^-8 mbar

Pressure Max

2.0 bar (abs)

Molecular flow conductance ls-1

14.0

Max. differential pressure (closed position in bar)

2

Max. pressure on seat side during opening in bar

1.0

Valve body temperature max. in °C

50.0

Actuator temperature max. in °C

50.0

Position indicator temperature max. in °C

0.0

Weight in kg/lbs

1.5 / 3.31
